Hot Sale CNC Horizontal Lathe CK61100 from China

Yogie as a heavy machine tool manufacturing company. the production of CK series 6180/61100 CNC horizontal lathe, rail width of 600mm length can be customized 1000mm to 20000mm,carrying more than 3tons Heavy series guide rail width can be divided 755mm,1100mm,1250mm,can carry 10-25tons,length can be customized 1000mm-20000mm welcome to choosing and ordering from our factory!
Product Details:

Hot sale CNC horizontal lathe CK61100 from China


A    Feature:

1.The whole machine body, body with large width side wall of double rib plate, inner strength plate adopts box type and diagonal reinforcement combination structure,the overall rigidity increased 1/3 than single wall struction.

2.Spindle with high precision bearings which mainly used for spindle, three support structure, strong rigidity, precision stability, bear large capacity  and can make strong cutting.

3.Knife rack automatic, machine body  guide rail small, surface using TSF wear-resistant layer structure, light and flexible movement, with long life.

4.The tailstock provided with a dial and the use of straight lines.

5.Customized 6 meters, 8 meters, 10 meters, 12 meters, 15 meters according to customer requirements

Detailed images



Item

Unit

CK61100

Capacities

Swing over bed

mm

1000

Swing over carriage

mm

615

Maximum length of workpiece

mm

1500 3000 5000 6000 8000 10000 12000

Maximum turning length

mm

1300 2800 4800 5800 7800 9800 11800

Span of guideway

mm

755

Spindle

Spindle nose

mm

A215 (8xM22)

Spindle bore

mm

130

Taper hole of spindle


1:20/140

Number of forward turning speeds


21

Number of reverse turning speeds


12

Spindle speed

Forward

r/min

3.15~315


Reverse

r/min

3.5~291

Feed motion

Number of feeds per revolution (longitudinal/transverse)


56/56

Feed per revolution

Longitudinal

mm

0.1~12(0.004"~0.473")


Transverse

mm

0.05~6(0.002"~0.236")


Upper tool-post

mm

0.025~3(0.001"~0.118")

Number and range of metric  thread


44,1~120mm

Number and range of inch thread


31,28~1/4"

Number and range of module thread


45,0.5~60mm

Number and range of diametrical pitch thread


38,1/2~56DP

Tool post

Distance between spindle centerline and tool resting plane

mm

48

Section of tool shank

mm

¨ 45

Tool post swing range

.

90·

Maximum travel of carriage

mm

1450 2950 4950 5950 7950 9950 11950

Maximum travel of top slide

mm

300

Maximum travel of cross slide

mm

520(20")  580(22")  630(24")

Tool post travel per turn of the dials of top or cross slide

mm

0.05(0.002")

rapid travel speed

Longitudinal

mm/min

3740


Transverse

mm/min

1870


Top slide

mm/min

935

Tailstock

Diameter of tailstock quill

mm

160(6")

Travel of tailstock quill

mm

300(12")

Taper hole of tailstock quill


Morse 6

Others

Main motor power

kw

22

Maximum weight of workpiece

kg

6000
