China Manufacturer offer Slewing Ring Bearing with High Precision

Luoyang Yujie Industry&Trade Co., Ltd is one of the most experienced manufacturers and suppliers of china manufacturer offer slewing ring bearing with high precision in China. Please feel free to buy cheap china manufacturer offer slewing ring bearing with high precision for sale here from our factory. All customized products are with high quality and competitive price.

Slewing ring bearing is a bearing which can be able to bear  large axial radial load and overturning torque.Slewing bearings are generally accompanied with mounting holes, internal gear ring and external gear ring,lubricating hole and sealing device,which enable mainframe structure compact in design,guide reliable,and easy to maintain.

Contact now

Slewing bearings are combination structure including non-gear,outside gear and four point contact ball bearings,double angular contact ball bearings.cross-cylindrical roller bearing and three rows cylindrical roller bearings and so on.In which,four point contact ball bearings have higher static load capacity,while cross-cylindrical roller bearings have higher dynamic load capacity.

Due to their excellent rotational support performance, slewing ring bearings are widely used in cranes, excavators, construction machinery, port machinery, and marine machinery. They can also meet the needs of large, high-precision rotating devices such as precision radar transmitters and missile launchers.

The selection of slewing bearings requires a comprehensive matching of four core dimensions: application scenario, load structure, accuracy level, and installation conditions. These factors directly determine the reliability and lifespan of the equipment.

Application areas dictate the choice of bearing type

Construction machinery (excavators, cranes) prioritizes single-row four-point contact ball bearings, balancing radial, axial, and overturning moments; heavy-duty equipment such as wind power and tunnel boring machines use double-row variable-diameter ball bearings or three-row roller bearings, increasing load capacity by over 30%; medical equipment and automated turntables prioritize light loads and high precision, selecting thin, compact slewing bearings; port machinery and metallurgical equipment primarily use three-row roller bearings, suitable for extremely large overturning moments.

Structural form matches load characteristics

Single-row four-point contact ball bearings offer high cost-effectiveness and are suitable for medium to light loads; double-row roller bearings have stronger axial load capacity; three-row roller bearings distribute radial, axial, and overturning moments separately, making them the first choice for heavy-duty conditions; geared structures are available with internal or external gears, selected based on transmission space and drive method, with the module increasing with the load.

Accuracy and Key Parameters

Accuracy is categorized into standard, precision, and high-precision grades. Automated equipment requires control of radial and axial runout. Rotational speed determines the lubrication method: grease lubrication is used for low speeds, while forced oil lubrication is required for high speeds. The sealing method should be either a labyrinth seal or a double-lip seal, suitable for harsh environments such as dust and humidity.

Furthermore, material heat treatment, installation dimensions, lubrication and sealing, and operating temperature are also crucial. These factors must be considered in conjunction with the equipment's operating conditions to ensure an optimal balance between load-bearing capacity, accuracy, lifespan, and cost.
