Luoyang Yujie Industry&Trade Co., Ltd is one of the most experienced manufacturers and suppliers of ck6140 turning machine cnc horizontal turning center in China. Please feel free to buy cheap ck6140 turning machine cnc horizontal turning center for sale here from our factory. All customized products are with high quality and competitive price.
| No | Item | CK6140H-750 | ||
| 1 | Maximum turning diameter of the machine | φ420mm | ||
| 2 | Maximum turning diameter of tool apron | φ230mm | ||
| 3 | Maximum workpiece length | 750mm | ||
| 4 | X-direction pallet maximum stroke | 220mm | ||
| 5 | Z-direction pallet maximum stroke | 550mm | ||
| 6 | Spindle through hole diameter | Φ66mm | ||
| 7 | Spindle speed range | 0～2500rpm Continuously variable speed | ||
| 8 | Spindle inner cone specification | MT6 | ||
| 9 | Spindle front end specification | A2-6 | ||
| 10 | main motor power | 7.5kW Servo spindle motor | ||
| 11 | Tailstock sleeve taper | MT4 | ||
| 12 | Tailstock sleeve diameter | 60mm | ||
| 13 | Tailstock sleeve stroke | 120mm | ||
| 14 | Positional accuracy | 0.01mm | ||
| 15 | Repeated positioning accuracy | ±0.005mm | ||
| 16 | Processing ellipticity | 0.004mm | ||
| 17 | Processing roughness | Ra1.6 | ||
| 18 | Number of electric tool holders | 4 | ||
| 19 | Clamp size | 25*25mm | ||
| 20 | Input power supply | 50Hz 380V | ||
| 21 | Net weight of machine tools | 1700kg | ||
| 22 | Outline size | 2340*1350*1600mm | ||
Features
1, Standard configuration GSK980TC3 bus system, 17-bit high-power absolute value feed servo, is the best combination of accuracy and efficiency;
2. One-piece casting of the whole bed, good rigidity and good stability;
3, Ultra-wide bed rails using high-quality HT250 castings, after two tempering stereotypes, hardness HRC55-62, X, Z two-axis pallets plastic, precision durable wear;
4, Fully enclosed double sliding door sheet metal, the system box can be rotated, the shape is beautiful, simple and applicable, dripping water does not leak;
5, A2-6 independent spindle + 7.5KW servo spindle gold combination, the highest speed of 2500rpm, pets and finishing freely switch, easy to use.
what we can do
We have a professional technical team to provide customers with lathes, machining centers, gantry boring and milling machine, and boring machine repair services, so that the machine that has been stopped can be resumed, leaving customers worry free .According to customer requirements, technicians put forward reasonable plans for ordinary lathes, machining centers, gantry and upgraded and upgraded the equipment to enable users to realize functional requirements and process higher quality products. Customer satisfaction is our consistent pursuit!
