Luoyang Yujie Industry&Trade Co., Ltd is one of the most experienced manufacturers and suppliers of casting steel ball mill liner plate in China. Please feel free to buy cheap casting steel ball mill liner plate for sale here from our factory. All customized products are with high quality and competitive price.
Products Description
Casting Steel Ball Mill Liner Plate is to protect the cylinder of a direct hit from grinding medium and material and friction,to increase grinding medium for material crushing effect, helps to improve the efficiency of the grinding mill, increase production, reduce consumption of metal. Different types of mill liners can be used to adjust the movement of materials.
Products show
Functions of ball mill liner plate
Protect the mill barrel: The liner plate acts as a sacrificial layer, shielding the barrel from the direct impact and abrasion caused by the grinding media and ore particles. This helps to prolong the service life of the mill shell and maintain its structural integrity.
Enhance grinding efficiency: The liner plate's smooth surface and appropriate design can facilitate the movement of the grinding media inside the mill, ensuring proper cascading and tumbling action. This improves the grinding efficiency and reduces energy consumption.
Reduce wear and tear: By providing a protective layer, the liner plate minimizes the wear and tear of the mill shell. It helps to prevent direct contact between the grinding media and the mill shell, reducing the friction and abrasive forces that contribute to liner and shell erosion.
Optimize milling performance: The design and configuration of the liner plate can be optimized to achieve specific milling objectives. Different liner profiles, such as wave, grid, or step liners, can be employed to control the trajectory and impact of the grinding media, thereby optimizing the milling process and achieving the desired product size distribution.
Easy installation and maintenance: Liner plates are typically bolted onto the mill shell, making them relatively easy to install and replace. This simplifies the maintenance and inspection of the mill, allowing for efficient and timely maintenance activities.
The material of ball mill lining plate needs to match the working conditions
High manganese steel has good toughness and is work-hardened by impact, making it suitable for rough grinding chambers and scenes where hard materials are subject to heavy impact; High chromium cast iron has high hardness, excellent wear resistance but high brittleness, and is mostly used in fine grinding chambers and small impact grinding conditions; The alloy steel has balanced comprehensive properties, taking into account wear resistance and toughness, and is suitable for small and medium-sized mills with medium impact; the rubber lining is corrosion-resistant, noise-reducing and weight-reducing, and is suitable for wet grinding environments; The ceramic lining plate is super wear-resistant and pollution-free, and is used for ultra-fine grinding to prevent iron pollution.
|
Material |
C |
Mn |
Cr |
Si |
Mo |
Ni |
Cu |
|
Mn13Cr2 |
1.1~1.4 |
12~15 |
1.7~2.2 |
0.3~1.0 |
|||
|
Mn18Cr2 |
1.1~1.4 |
17~19 |
1.8~2.2 |
0.3~1.0 |
|||
|
Cr12 |
2.0~3.3 |
≤2.0 |
11~14 |
≤1.2 |
≤3.0 |
≤2.5 |
≤1.2 |
|
Cr15 |
2.0~3.3 |
≤2.0 |
11~14 |
≤1.2 |
≤3.0 |
≤2.5 |
≤1.2 |
|
Cr20 |
2.0~3.3 |
≤2.0 |
14~18 |
≤1.2 |
≤3.0 |
≤2.5 |
≤1.2 |
|
Cr26 |
2.0~3.3 |
≤2.0 |
23~30 |
≤1.2 |
≤3.0 |
≤2.5 |
≤2 |
Contact us
Do you have any specific questions about the design or manufacture of ball mill liner plates? Contact Yogie!
FAQ
Q: Are you trader or factory?
Q: What kind of service can you provide?
Q: Will weld inspection and paint thickness inspection be performed?
A: Yes. We also support third-party testing.
Q: Do you support factory inspection?
A: Anytime
Q: Besides manufacturing spare parts for large machinery, what else do you produce?
A: We also manufacture large CNC machine tools and perform equipment upgrades and retrofits.
