CNC lathe CK6150B/CK6163A Machining Center
Products Description
A CNC lathe machining center, also known as a CNC turning center, is a highly automated and computer-controlled machine used for precision machining operations. It combines the capabilities of a lathe and a machining center, allowing for the production of complex parts with high accuracy.
Products show
|
Number |
Details |
CK6150B/6163A-1000/1500/2000/3000 |
|
1 |
Maximum turning diameter on the bed |
Φ500mm/Φ630mm |
|
2 |
Maximum turning diameter of X direction pallet |
Φ290mm/Φ420mm |
|
3 |
Double top distance |
1000mm/1500mm/2000mm/3000mm |
|
4 |
Spindle nose specifications |
A2-8/D8 |
|
5 |
Spindle taper |
Metric1：20 |
|
6 |
Spindle through hole |
Φ82mm/Φ78mm |
|
7 |
Spindle transmission form |
Manual third gear, stepless in the gear |
|
8 |
Spindle speed range |
60-1600rpm |
|
9 |
Maximum travel in X direction |
280mm |
|
10 |
Maximum travel in Z direction |
850mm/1350mm/1850mm/2850mm |
|
11 |
Outer diameter of tailstock sleeve |
Φ75mm |
|
12 |
Inner taper of tailstock sleeve |
MT5 |
|
13 |
Tailstock sleeve travel |
165mm |
|
14 |
X axis fast speed |
6m/min |
|
15 |
Z axis fast speed |
12m/min |
|
16 |
Positioning accuracy |
X ≤ 0.03mm,Z ≤ 0.04mm |
|
17 |
Repeatability accuracy |
X ≤ 0.005mm,Z≤0.010mm |
|
18 |
Processing roundness |
0.004mm |
|
19 |
Workpiece surface roughness |
Ra1.6 |
|
20 |
Knife holder |
Four-station electric knife holder |
|
21 |
Tool section size |
25*25mm |
|
22 |
Main motor specifications |
7.5kw asynchronous frequency conversion |
|
23 |
Chuck specifications |
Three-jaw chuck Φ250mm |
|
24 |
Rail width |
390mm |
|
25 |
Sheet metal style |
Double sliding door fully closed |
|
26 |
Overall dimensions |
3000*1700*1800mm |
|
27 |
Machine weight |
Approx 2800kg/3200kg/3800kg/4500kg |
functions and features of cNC lathe
Turning Operations: The primary function of a CNC lathe machining center is to perform turning operations. It rotates the workpiece while a cutting tool removes material to create cylindrical or conical shapes. It can perform various turning operations such as facing, contouring, tapering, threading, and grooving.
Computer Numerical Control (CNC): CNC technology is at the core of a CNC lathe machining center. It utilizes computer programming and numerical control to automate and control the machine's operations. The CNC system receives instructions in the form of a program, which contains the tool paths, cutting parameters, and other commands to perform the desired machining operations.
Automatic Tool Changing: CNC lathe machining centers are equipped with automatic tool changers (ATCs) that allow for the rapid exchange of cutting tools. This feature enables the machine to perform multiple operations without manual intervention, improving productivity and reducing setup time.
Axis Movement: CNC lathes typically have multiple axes of movement to achieve complex machining tasks. The main axes include:
X-Axis: Controls the horizontal movement of the cutting tool along the workpiece.
Z-Axis: Controls the longitudinal movement of the cutting tool along the workpiece axis.
C-Axis (optional): Some CNC lathe machining centers have a C-axis, which enables the rotation of the workpiece or the spindle at specific angles. This is useful for performing operations such as milling, drilling, or creating features at non-linear orientations.
Spindle and Chuck Control: CNC lathe machining centers have a spindle that rotates the workpiece. The CNC system controls the spindle speed, direction, and acceleration to ensure precise machining. The chuck, which holds the workpiece, can also be controlled automatically to grip or release the workpiece as needed.
Programmability and Flexibility: CNC lathe machining centers offer high programmability, allowing for the production of a wide range of parts with different shapes, sizes, and complexities. The CNC system can store and execute multiple programs, enabling efficient batch production and quick changeovers between different part setups.
Monitoring and Feedback: CNC lathe machining centers often have sensors and feedback systems to monitor various parameters, such as tool wear, temperature, and cutting forces. This data can be used to optimize machining processes, detect errors, and ensure the quality and accuracy of the produced parts.
Integration with CAD/CAM Systems: CNC lathe machining centers are compatible with computer-aided design (CAD) and computer-aided manufacturing (CAM) software. This integration enables the creation and simulation of machining programs, tool paths, and part designs before actual production, enhancing efficiency and accuracy.
Applications of CNC lathe
CNC lathe machining centers are widely used in industries such as automotive, aerospace, medical, and general manufacturing, where high precision and productivity are crucial. They offer advanced machining capabilities and automation, making them versatile and efficient tools for producing complex parts.
Configuration feartures
1. Standard configuration GSK980TC3 bus system, 17-bit high-power absolute value feed servo, is the best combination of accuracy and efficiency;
2. The integrally cast integral bed foot has good rigidity and good stability;
3. Fully enclosed double sliding door sheet metal, system box and rotation, beautiful shape, suitable for introduction, no dripping;
4. The bed of high-quality HT250 casting is shaped by secondary tempering, the hardness is HRC55-62, the precision is durable and wear-resistant;
5. The golden combination of the main gear box with manual third gear +11KW high-match inverter, the maximum speed is 1600rpm, the heavy cutting and finishing can be switched freely, and the cutting edge is more than free
