Luoyang Yujie Industry&Trade Co., Ltd is one of the most experienced manufacturers and suppliers of horizontal turning lathe in China. Please feel free to buy cheap horizontal turning lathe for sale here from our factory. All customized products are with high quality and competitive price.
A horizontal turning lathe, also known as a horizontal lathe or a turning center, is a type of machine tool used for precision machining of cylindrical workpieces. The primary function of a horizontal turning lathe is to rotate a workpiece on its axis while cutting or shaping it using various cutting tools. This type of lathe is characterized by its horizontal orientation, where the workpiece is held parallel to the ground.
features
Bed and Base:
The lathe has a horizontal bed and base that provide a stable platform for mounting various components.
Headstock:
The headstock contains the spindle, which holds and rotates the workpiece. It may also include gears and speed controls to adjust the rotational speed.
Tailstock:
The tailstock supports the other end of the workpiece and can be moved to accommodate different lengths of workpieces. It may also have a quill for additional support.
Tool Rest:
A tool rest or tool turret holds the cutting tools that are used to shape the workpiece. The turret allows for quick tool changes.
Carriage:
The carriage is a movable component that holds the cutting tools and can be traversed along the length of the bed to perform turning operations.
Control Panel:
Modern horizontal turning lathes often feature computer numerical control (CNC) systems. These systems allow for precise control of the cutting tools and automated machining processes.
Functions
Turning:
The primary function is turning, where the lathe shapes the workpiece by removing material from its outer surface.
Facing:
Horizontal lathes can be used for facing operations, creating a flat surface on the end of the workpiece.
Taper Turning:
Taper turning involves creating a conical shape on the workpiece, and horizontal lathes can be equipped to perform this function.
Threading:
Lathes can be equipped with threading capabilities to cut threads on cylindrical workpieces.
Drilling:
Some horizontal turning lathes are equipped with live tooling, allowing them to perform drilling operations on the workpiece.
Automated Production:
With CNC capabilities, horizontal turning lathes can be used for high-precision and automated production of complex parts, enhancing efficiency and accuracy.
Mass Production:
These lathes are suitable for mass production of components with consistent and precise dimensions.
application
Horizontal turning lathes are commonly used in industries such as aerospace, automotive, and general machining where precision turning of cylindrical parts is required. They are versatile machines capable of handling a wide range of materials and producing various shapes and sizes of
components.
main parameters
|
No |
Item |
CK6163 |
CK6180 |
CK61100 |
CK61125 |
|
1 |
Maximum turning diameter on the bed(mm) |
630 |
800 |
1000 |
1250 |
|
2 |
Maximum turning diameter of X-direction pallet(mm) |
350 |
500 |
660 |
850 |
|
3 |
Maximum workpiece length(mm) |
1000/1500/2000/3000 |
1000/1500/2000/3000 |
1500/2000/3000 |
1500/2000/3000 |
|
4 |
Length of bed rail(mm) |
550 |
600 |
660 |
755 |
|
5 |
Maximum workpiece load(T) |
2T |
3T |
4T |
5t-8T |
|
6 |
Spindle rotation form |
Three-speed mechanical transmission, stepless speed regulation in the gear |
Four-speed mechanical transmission, stepless speed regulation in the gear |
||
|
7 |
Spindle speed range(rpm) |
25-800 |
25-800 |
15-600 |
5-400 |
|
8 |
Spindle end structure |
C11 or D11 |
C11 or D11 |
C11 or D11 |
A2-15 |
|
9 |
Thru-hole of spindle(mm) |
105 |
105 |
130 |
130 |
|
10 |
Taper of the front end of the spindle hole |
Metric120,1：20 |
Metric120,1：20 |
Metric140,1：20 |
Metric140,1：20 |
|
11 |
Maximum stroke of tool holder(mm) |
X:530 |
X:550 |
X:530 |
X:560 |
|
12 |
Roller screw specifications |
X:3205/Z:5010-6310 |
X3205/5010-6310 |
X3205/5010-6310 |
X:5008/Z:8012 |
|
13 |
Moving speed(mm/min) |
X:6000/Z:10000 |
X:6000/Z:10000 |
X:5000/Z:8000 |
X:4000/Z:6000 |
|
14 |
Positioning accuracy(mm) |
X:0.02/Z:0.03 |
X:0.02/Z:0.03 |
X :0.030 Z :0.045 |
X ：0.030 Z :0.045 |
|
15 |
Repositioning Accuracy(mm) |
X:0.075/Z:0.01 |
X:0.075/Z:0.01 |
X:0.075/Z:0.015 |
X:0.075/Z:0.015 |
|
16 |
Workpiece machining accuracy |
IT6-IT7 |
IT6-IT7 |
IT7 |
IT7 |
|
17 |
Workpiece surface roughness |
Ra1.6 |
Ra1.6 |
Ra3.2 |
Ra3.2 |
|
18 |
Tailstock sleeve diameter(mm) |
100 |
100 |
Φ100 |
160 |
|
19 |
Tailstock sleeve travel(mm) |
250 |
250 |
250 |
300 |
|
20 |
Specification of taper hole of tail-sleeve sleeve |
MT6 or MT5 |
MT6 or MT5 |
MT6 |
Metric80mm 1：20 |
|
21 |
Cutter section size(mm) |
32*32 |
32*32 |
40*40mm |
45*45 |
|
22 |
Machine dimensions(mm) |
3700*1820*1780 |
3700*1820*1780 |
3900*2000*1780 |
3900*2000*1780 |
|
23 |
Total Weight(kg) |
Approx 4200/4600/4800/5000 |
Approx 4500/5000/5500/6500 |
Approx 5600/6400/7500 |
Approx 6000/7000/9000 |
