CNC lathe T30 Machining Center
Configuration features:
1. Standard configuration GSK980TC3 bus system, 17-bit high-power absolute value feed servo, is the best combination of accuracy and efficiency;
2. The bed and foot of the bed are integrally cast, with good rigidity and good stability;
3. The main shaft hopes to use P4 custom bearings to achieve the best balance between speed and bearing capacity;
4. Standard configuration of Taiwan Yintai linear guide rail and ball screw, P4 grade screw positioning bearing produced by TPI;
5. Knife arrangement structure, fast tool change, and high precision;
6. Standard configuration of pneumatic spring chuck, optional 6-inch hollow hydraulic chuck;
7. Fully enclosed protective sheet metal, no dripping;
8. Reserve space for the manipulator of the rack, which can realize the automatic production line.
No. | Item | T30 |
1 | Maximum turning diameter on the bed | Φ320mm |
2 | Maximum turning diameter of X-direction pallet | Φ70mm |
3 | Spindle nose specifications | A2-5 |
4 | Spindle through hole | Φ42 |
5 | Work clamping method | Spring collet/hydraulic chuck |
6 | Spindle speed range | 60-3500rpm |
7 | Maximum travel in X direction | 560mm |
8 | Maximum travel in Z direction | 330mm |
9 | X axis fast speed | 24m/min |
10 | Z axis fast speed | 24m/min |
11 | Positioning accuracy | 0.01mm |
12 | Repeatability accuracy | 0.005mm |
13 | Processing roundness | 0.003mm |
14 | Workpiece surface roughness | Non-ferrous metal Ra0.4/steel Ra1.6 |
15 | Knife holder | Row knife |
16 | Tool section size | 20*20mm |
17 | Main motor power | 3.7kw |
18 | Sheet metal style | Single sliding door fully closed |
19 | Overall dimensions | 1580*1250*1680mm |
20 | Machine weight | Approx 1200kg |
