RB Series Crossed Roller Bearing YOGIE High Precision CNC Bearings

RB Series Crossed Roller Bearing YOGIE High Precision CNC Bearings

Name: RB Series Crossed Roller Bearing YOGIE High Precision CNC Bearings
Brand: Yujie
SKU: 83985038

Material:GCr15/ GCr15SiMn
Size:as per customer drawing and requirements
Precision:P2,P4,P5
Processing:Lathing, milling,grinding,drilling
Heat treatment:Annealing, normalizing, quenching or tempering
Service:OEM ODM
Certification:ISO SGS
Packing:according to customers requests

Send Inquiry

Description

YOGIE RB Series Crossed roller bearings are lightweight, compact bearings with thinnest possible inner and outer rings with high rigidity, because of its vertical arrangement of cylindrical rollers with a 90°V groove through the separate spacers in the deep groove rolling surface. This special design allows just one bearing to carry loads in all directions including radial, axial and moment loads.

Series Introduction:RB standard type is a bearing with thinnest possible inner and outer rings because the outer ring is split while the inner ring is integrated into the main body. It is being used in cases where a high rotational accuracy of the inner ring is required

Shaft diameter(mm)	Model number	Main dimensions(mm)						Shoulder height	Basic load rating(radial)			weight
Shaft diameter(mm)	Model number	Inner ring d(mm)	Outer ring D(mm)	dp	Width B B1	Greasing hole	r（min）	ds （mm）	Dh(mm)	C kN	Co kN	Kg
30	RB3010	30	55	41.5	10	1	0.6	37	47	7.35	8.36	0.12
35	RB3510	35	60	46.5	10	1	0.6	41	51.5	7.64	9.12	0.13
40	RB4010	40	65	51.5	10	1	0.6	47.5	57.5	8.33	10.6	0.16
45	RB4510	45	70	56.5	10	1	0.6	51	61.5	8.62	11.3	0.17
50	RB5013	50	80	64	13	1.5	0.6	57.4	72	16.7	20.9	0.27
60	RB6013	60	90	74	13	1.5	0.6	68	82	18	24.6	0.3
70	RB7013	70	100	84	13	1.5	1	78	92	19.4	27.7	0.35
80	RB8016	80	120	98	16	1.5	1	91	111	30.1	42.1	0.7
90	RB9016	90	130	108	16	1.5	1.5	98	118	31.4	45.3	0.75
100	RB10016	100	140	119.3	16	1.5	1.5	109	129	31.7	48.6	0.83
100	RB10020	100	150	123	20	1.5	1.5	113	133	33.1	50.9	1.45
110	RB11012	110	135	121.8	12	1.5	1	117	127	12.5	24.1	0.4
	RB11015		145	126.5	15	1.5	1	122	136	23.7	41.5	0.75
	RB11020		160	133	20	1.5	1.5	120	143	34	54	1.56
120	RB12016	120	150	134.2	16	1.5	1.5	127	141	24.2	43.2	0.72
120	RB12025	120	180	148.7	25	2	1	133	164	66.9	100	2.62
130	RB13015	130	160	144.5	15	1.5	2	137	152	25	46.7	0.72
130	RB13025	130	190	158	25	2	1	143	174	69.5	107	2.82
140	RB14016	140	175	154.8	16	1.5	2	147	162	25.9	50.1	1
140	RB14025	140	200	168	25	2	1.5	154	185	74.8	121	2.96
150	RB15013	150	180	164	13	1.5	2	157	172	27	53.5	0.69
	RB15025		210	178	25	2	1	164	194	76.8	128	3.16
	RB15030		230	188	30	3	2	173	211	100	156	5.3
160	RB16025	160	220	188.6	25	2	2	173	204	81.7	135	3.14
170	RB17020	170	220	191	20	1.5	2	184	198	29	62.1	2.11
180	RB18025	180	240	210	25	2	2	195	225	84	143	3.44
190	RB19025	190	240	211.9	25	1.5	2	202	222	41.7	82.9	2.99
200	RB20025	200	260	230	25	2	2.5	215	245	84.2	157	4
	RB20030		280	240	30	3	2.5	221	258	114	200	6.7
	RB20035		295	247.7	35	3	2.5	225	270	151	252	9.6
220	RB22025	220	280	250.1	25	2	2.5	235	265	92.3	171	4.1
240	RB24025	240	300	269	25	2	3	256	281	68.3	145	4.5
250	RB25025	250	310	277.5	25	2	3	265	290	69.3	150	5
	RB25030		330	287.5	30	3	3	269	306	126	244	8.1
	RB25040		355	300.7	40	3.5	3	275	326	195	348	14.8
300	RB30025	300	360	328	25	2	3	315	340	76.3	178	5.9
	RB30035		395	345	35	3	3	322	368	183	367	13.4
	RB30040		405	351.6	40	3.5	3	326	377	212	409	17.2
350	RB35020	350	400	373.4	20	1.5	3.5	363	383	54.1	143	3.9
400	RB40035	400	480	440.3	35	3	3.5	422	459	156	370	14.5
400	RB40040	400	510	453.4	40	3.5	1.5	428	479	241	531	23.5
450	RB45025	450	500	474	25	1.5	1.5	464	484	61.7	182	6.6
500	RB50025	500	550	524.2	25	1.5	1.5	514	534	65.5	201	7.9
	RB50040		600	548.8	40	3	3.5	526	527	239	607	26
	RB50050		625	561.6	50	3.5	3.5	536	587	267	653	41.7
600	RB60040	600	700	650	40	3	4	627	673	264	721	29
700	RB70045	700	815	753.5	45	3	4	731	777	281	836	46
800	RB80070	800	950	868.1	70	4	5	836	900	468	1330	105
900	RB90070	900	1050	969	70	4	5	937	1001	494	1490	120
1000	RB1000110	1000	1250	1114	110	6	6	1057	1171	1220	3220	360
1250	RB1250110	1250	1500	1365.8	110	6	6	1308	1423	1350	3970	440

Application:

•Industrial Robotic arm,Reducer drive

•precision Turntable,NC rotary table

•Rotation part of Machine tools

•Inspection instrument,Medical equipment

• Aviation equipment,Military radar etc

Luoyang Yujie Industry &Trade Co.Ltd located in Luoyang City, one of the main heavy industrial bases in China.

We specialize in the production of bearings, nonstandard machinery parts, machine tools. For the bearings, we can offer cross roller bearing, slewing bearing, YRT bearing, thin section bearing, ball screw bearing, deep groove ball bearing, etc. For the nonstandard machine parts, we can produce gears, shafts, sprockets, molds, rollers, pulley, mining machine parts, etc as per customer drawing and requirements. For the machine tools, we offer CNC vertical machine center, CNC horizontal lathe, CNC gantry boring and milling machine, CNC floor type boring, and milling machine.

If you have any interests, feel free to contact us and we warmly welcome customers and friends visit us
