A trunnion is a cylindrical protrusion used as a mounting or pivoting point. First associated with cannons, they are an important military development.
Alternatively, a trunnion is a shaft that positions and supports a tilting plate. This is a misnomer, as in reality it is a cradle for the true trunnion.
Trunnion positions saw table and provides a pivot point.
In mechanical engineering, it is one part of a rotating joint where a shaft (the trunnion) is inserted into (and turns inside) a full or partial cylinder.
In mechanical engineering, it is one part of a rotating joint where a shaft (the trunnion) is inserted into (and turns inside) a full or partial cylinder. Often used in opposing pairs, this joint allows tight tolerances and strength from a large surface contact area between the trunnion and the cylinder.
In airframe engineering, these are self-contained concentric bearings that are designed to offer fluid movement in a critical area of the steering.
The term is also used to describe the wheel that a rotating cylinder runs on. For example, a lapidary (stone-polishing) cylinder runs on a pair of rollers, similar to trunnions. The sugar industry uses rotating cylinders up to 22 feet (7 m) in diameter, 131 ft (40 m) long, and weighing around 1,000 tons. These rotate at around 30 revolutions per hour. They are supported on a pathring, which runs on trunnions. Similar devices called rotary kilns are used in cement manufacturing.
In mining, some refining plants utilise drum scrubbers in the process that are supported by a large trunnion and associated trunnion bearings at each end.
